Image sensor
1/1.8″ Progressive Scan CMOS
Lens
Focal Length: 2.8 to 12 mm
Day / Night
Day / Night / Auto / Customize / Schedule
Minimum illumination
Color: 0.001Lux@F1.2
B/W: 0 Lux with IR on
Shutter time
Video Compression
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Resolution
Frame rate
M_Stream: 60Hz: 60Hz: 60fps@(2688×1520, 2304×1296, 1920×1080,1280×720)
50Hz: 50fps@(2688×1520, 2304×1296, 1920×1080,1280×720))
Sub_Stream: 60Hz: 60fps@(704x576, 640x480, 640x360)
50Hz: 50fps@(704x576, 640x480, 640x360)
Third_Stream: 60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360)
50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360)
Quaternary_Stream: 60Hz: 10fps@(1280x720), 30fps@(704x576, 640x480, 640x360)
50Hz: 10fps@(1280x720), 25fps@(704x576, 640x480, 640x360)
Video streaming
Image settings
White Balance, BLC, HLC, 2D DNR, 3D DNR, AGC, Defog, Deblur, Anti-flicker, LDC, DIS, 140dB WDR, Privacy mask Up to 8 areas, ROI up to 8 area, Up to 32X Hybrid Zoom
Audio streaming
Audio Compression
Audio IN/OUT
1 Audio Intput Interface
1 Audio Output Interface
Compatible Integration
ONVIF Profile G & M & S & T, One API
Supported protocols
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, LLDP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, VPN, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2
Analytics
Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Line Crossing, Loitering, Object Left, Object Removed. Detect up to 50 targets, Attribute Recognition, Face Detection, Object Counting & Report, Heat Map, Hat detection, Privacy Protection, Fall Detection, Violence Detection
Events
Motion Detection, Tamper Detection, Audio Alarm, External Input, External Output, Network Disconnection, IP Address Conflict, Record Failed, SD Card Full, SD Card Uninitialized, SD Card Error, No SD Card
Protection Certificate
IP67
IK10
Surge Protection 6KV
Power
DC 10V~DC 28V, PoE+ (802.3at)
Power Consumption: Min. 3.4W (DC), 4.1W (PoE+), Max. 13.8W (DC), 16.2W (PoE+)
Connectors
Alarm I/O: 1/1
Network: 1*RJ45 10M/100M Ethernet Port
Storage
Edge Storage: Micro SD/SDHC/SDXC Card Local Storage, up to 1TB
Network Storage: NAS (Support NFS, SMB/CIFS), ANR
Operation Condition
-40℃ ~60℃(-40°F~ 140°F)
0~95% RH (Non-condensing)
Approvals
EMC:
CE-EMC (EN 55032, EN 55035, EN 50130-4)
FCC (Part 15B)
Safety:
UL: UL 62368-1
CE-LVD (EN IEC 62368-1)
Environment:
CE-ROHS (Directive (EU) 2015/863 amending 2011/65/EU)
Dimensions (L * W * H)
Weight
Net: Approx. 1.6kg
Gross: Approx. 2.4kg
