AAI-244080-W
Aurora AAI-244080-W White- light Illuminator
- Adapted with super brightness white light LED to provide powerful illumination at night time
- IK10 degree of protection against mechanical impacts
- IP68 waterproof level
- Electric variable angle control via RS485 by zoom camera
- Remote control provides easy set up
- External input for LED ON/OFF
- External output for day/night switch
- Low failure rate is guaranteed by the professional in-house optimized independent circuit technology
- Flexible angle-adjustable bracket fit for various installation site
- Robust cooling fin design is available to long term working at -50℃ to 55℃
- 50,000 hours lifetime of LED
- 5 years warranty
Specifications
| Technical Specification | |
| LED Type | 24pcs high brightness LED |
| Color Temperature | 6000-6500K |
| Power Consumption | Max. 80W |
| Beam Angle | 40°-80° |
| Distance | 90m-50m |
| Beam Shape | Round |
| Auto ON/OFF | by light sensor |
| Manual ON/OFF | by remote control |
| Power Adjustment | by remote control |
| Beam Angle Adjustment | by RS485 PELCO-D, (other protocols are available to customize) or remote control |
| Light Sensor Sensitivity | 10/20/50/100% |
| Power |
|
| Operating Environment | -40℃ to 55℃ |
| Working Temperature | -40℃ to 55℃ |
| Wire Length | 1.5 meter |
| Protection Level | IK10, IP68 |
| Working Humidity | 0.9 |
| Color | Black |
| Bracket | Flexible U bracket |
| Net Weight | 2.6kg |
| Gross Weight | 3kg |
| Dimension | 220*160*74 mm |
| Packing Dimension | 250*290*170 mm |
| Certificates | ISO9001-2015, CE /FCC/ ROSH /IK10/ IP68 |
| Ordering information | |
| AAI-244080-WD | 24V DC ±10% |
| AAI-244080-WA | 24V AC(50/60Hz) ±10% |
| AAI-244080-WP | POE |
| Optional Accessories | Power Supply Unit (PSU) |
Documentations
Please download the technical documents here
